Short Description:
Working size: 28" x 20" (700 mm × 500 mm)
Laser Tube: RECI 90 W CO2 glass laser tube
Certification: FDA certified
Power Supply: AC 110 V ± 10%, 60 Hz
Working Platform: Motorized up and down working table, suitable for MAX 210mm high object.
Focusing Type: Double red dot focusing
Suitable for Material: Acrylic / Wood Board ( Rare Hard Wood ) / Density Board (High Density Board) / Double Color Plate / PVC / Leather / Cloth / Paper
Others: Built-in Air Pressure adjustment help you get best effect during cutting and engraving
Product Description:
Technical Details:
| Model | COL750B |
| Work area | 700 x 500mm ( 27.56 x 19.68 in) |
| Laser tube power | RECI 90W |
| Engraving speed | 1000mm/s 40 in/s |
| Cutting speed | 400mm/s 15 in/s |
| Cutting depth of acrylic | 20mm ( A signal cutting) 0.8 in |
| Work table | Aluminum blade |
| Motorized Z | 210mm( 8.27”) |
| Minimum forming character | 1*1mm |
| Max Scanning Precision | 4000DPI |
| Positioning precision | 0.01mm |
| Power supply | AC 110 V ± 10%, 60 Hz |
| Gross Power | 900W |
| Auto Focus | Double Red Dot |
| Rotary Device | Standard |
| Water Chiller | Optional CW3000 |
| Built-in Wifi | Optional |
| Honey Comb Plate | Optional |
| Air compressor | Optional |
| Machine Dimension (L x W x H) | 55.51" x 35.43" x 43.31" 141 x 90 x 45.67cm |
| Packing Size (L x W x H) | 59.84" x 42.13" x 35.43" 152 x 107 x 90cm |
| Weight | NW 348LB / GW 463LB 158kg/210kg |
